Motor
Giant SyncDrive Sport2, 75Nm, PedalPlus 6-sensor technology
-
Controller
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
-
Display
Giant RideControl Dash, high-angle visibility, full color LCD display
-
Battery
Giant EnergyPak 500Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 250 range extender compatible
-
Charger
Giant EnergyPak 4A smart charger compact, 60% charge in 2:00h
-
Sizes
S, M, L, XL
-
Colours
Black Diamond
-
Frame
ALUXX SL-grade aluminum, 1.5"~1.8" head tube,125mm travel FlexPoint suspension system, 'Boost' 148x12 UDH rear axle, EnergyPak Plus Range Extender Compatible
-
Fork
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
-
Shock
SR Suntour Raidon R, 190x45mm, recommended sag: 30%
-
Handlebar
Giant Connect TR Riser 31.8x780mm
-
Grips
Giant Tactal single lock-on
-
Stem
Giant Contact
-
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
-
Saddle
Giant Sport
-
Pedals
N/A
-
Shifters
Shimano Deore LinkGlide
-
Front Derailleur
MRP HD2 co-moulded chain guide
-
Rear Derailleur
Shimano Deore LinkGlide, 10-speed
-
Brakes
Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
-
Brake Levers
Tektro HD-M745 Orion
-
Cassette
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
-
Chain
Shimano, LinkGlide, CN-LG500
-
Crankset
FSA Comet E-Bike crank arm set FSA MegaTooth Direct-mount 1X steel 36T
-
Bottom Bracket
n/a
-
Rims
Giant AM30, Tubeless ready, 30mm inner width, 29"
-
Hubs
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
-
Spokes
Stainless Steel
-
Tires
Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 29X2.40" WT Foldable, TLR, EXO, 60TPI [R]
-
Extras
-
-
Lighting
-
-
Lock
Torx 25 Battery Lock with built-in Torque limiter
-
Carrier
-
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
