Motor
SyncDrive Pro2, 85Nm, powered by Yamaha
-
Controller
RideControl Ergo 3, grip integrated
-
Display
RideControl GO, frame integrated LED display ANT+ Wireless display compatible
-
Battery
EnergyPak Smart 400Wh EnergyPak Plus 200Wh range extender compatible
-
Charger
Giant EnergyPak 4A smart charger, 60% in 1:45
-
Connectivity
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
-
Sizes
S, M, L, XL
-
Colours
Messier/Panther
-
Frame
Advanced-Grade Composite front triangle, ALUXX SL-Grade rear triangle, Advanced Forged Composite upper rocker, 140mm Maestro suspension, 12x148 thru-axle, flip chip - Maestro
-
Fork
Marzocchi Bomber Z2 E-Tuned, 29er, 150mm travel, 44mm offset, RAIL damper Sweep-Adj, Kabolt 110
-
Shock
Fox Float Performance, EVOL Large Volume sleeve, 2pos, 185x52.5mm Trunnion mount, custom tuned, recommended sag: 30%
-
Handlebar
Giant Contact SL 35 Trail, 35x780mm
-
Grips
Giant Tactal Pro-E, tapered design, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL)
-
Stem
Giant Contact SL 35
-
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170) (*3mm housing recommended)
-
Saddle
Giant Romero, Neutral
-
Pedals
n/a
-
Shifters
Shimano Deore
-
Front Derailleur
MRP HD2 co-moulded chain guide
-
Rear Derailleur
Shimano Deore 12-speed, Shadow+
-
Brakes
Shimano BR-MT420, 4-piston, hydraulic disc,203mm [F/R]
-
Brake Levers
Shimano Deore, I-spec EV
-
Cassette
Shimano CS-M6100-12, 10-51T, 12-speed
-
Chain
KMC e.12 Turbo, EcoProteq, e-bike optimized
-
Crankset
Praxis N.W. 36T Cold Forged 4130 premium steel Praxis e-Cranks (Q-factor=168, S:160, M/L:165, XL:170)
-
Bottom Bracket
n/a
-
Rims
Giant AM30, Tubeless ready, 30mm inner width, 29" [F] / 27.5" [R]
-
Hubs
Shimano MT410 Boost, Center-Lock, 110x15 [F] 148x12 Shimano Micro-Spline Drive Body Thru-axle [R]
-
Spokes
Sapim E-Lite [R] Race [F], e-bike optimized
-
Tires
Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO [F]Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R]
-
Extras
Tubeless kit (liquid, valves, levers, manual, tool)Inner tube supplied
-
Lighting
Optional:- Giant Recon series e-bike lights available and direct connectable
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
