Frame
ALUXX-Grade Aluminum, disc
Fork
SXC32-2 RL, air spring, QR, alloy steerer S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (27.5) / 100mm travel (29) / 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)
Shock
N/A
Handlebar
Giant Connect Trail, 31.8mm XS: 730mm (27.5) S: 780mm (27.5) / 780mm (29) M: 780mm (27.5) / 780mm travel (29) L: 780mm (27.5) / 780mm (29) XL: 780mm (29) XXL: 780mm (29)
Grips
Giant Sole-O
Stem
Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (27.5) / 60mm travel (29) L: 70mm (27.5) / 70mm (29) XL: 80mm (29) XXL: 90mm (29)
Seatpost
Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (27.5) / 375mm (29) XL: 375mm (29) XXL: 375mm (29)
Saddle
Giant custom
Pedals
MTB caged
Shifters
Shimano Deore M4100, 1x10
Front Derailleur
N/A
Rear Derailleur
Shimano Deore M5120
Brakes
Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm
Brake Levers
Tektro HDC M275
Cassette
Shimano Deore M4100, 11x42
Chain
KMC X10
Crankset
ProWheel Charm, 30t (27.5) or 32t (29) XS: 165mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (27.5) / 175mm travel (29) L: 175mm (27.5) / 175mm (29) XL: 175mm (29) XXL: 175mm (29)
Bottom Bracket
cartridge
Rims
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Hubs
alloy, sealed bearing
Spokes
stainless, 14g
Tires
Kenda Booster 27.5 or 29x2.4", wire bead
Extras
2.4" max tire size
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
