Frame
ALUXX-Grade Aluminum, disc
Fork
SXC32-2 RL 29, air spring, QR, alloy steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (27.5) / 100mm travel (29) L: 100mm travel (27.5) / 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)
Shock
N/A
Handlebar
Giant Connect Trail, 31.8mm XS: 730mm (27.5) S: 780mm (27.5) / 780mm (29) M: 780mm (27.5) / 780mm travel (29) L: 780mm (27.5) / 780mm (29) XL: 780mm (29) XXL: 780mm (29)
Grips
Giant Sole-O
Stem
Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (27.5) / 60mm travel (29) L: 70mm (27.5) / 70mm (29) XL: 80mm (29) XXL: 90mm (29)
Seatpost
Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (27.5) / 375mm (29) XL: 375mm (29) XXL: 375mm (29)
Saddle
Giant custom
Pedals
MTB caged
Shifters
Shimano Deore M6100, 1x12
Front Derailleur
N/A
Rear Derailleur
Shimano Deore M6100
Brakes
Shimano Deore BR-MT200, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm **some bikes may be substituted: Tektro TKD143, hydraulic [F] 180mm, [R]160mm
Brake Levers
Shimano BL-MT200 **some bikes may be substituted: Tektro TKD143
Cassette
Shimano Deore M6100, 10x51
Chain
KMC X12
Crankset
ProWheel MPX, 30t (27.5) or 32t (29) XS: 165mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (27.5) / 175mm travel (29) L: 175mm (27.5) / 175mm (29) XL: 175mm (29) XXL: 175mm (29)
Bottom Bracket
cartridge
Rims
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Hubs
Shimano, sealed bearing
Spokes
stainless, 14g
Tires
Kenda Booster 27.5 or 29x2.4", wire bead
Extras
2.4" max tire size, 32t max chainring size
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
