Frame Spec
Frame: Hi-ten steel frame w/ standard head tube, Mid BB, top tube gusset w/ Verde logo
Top Tube Length: 20.25”
Chain Stay Length 13.5”
Head Tube Angle: 74.5º
Seat Tube Angle: 71º
Bottom Bracket Height: 11.7”
Standover Height: 8.8”
Parts Spec
Fork: Hi-ten steel w/ 2-piece steerer tube, tapered legs
Bars: Hi-ten steel, 9” rise
Stem: Verde top load, 50mm reach
Headset: Standard 1-1/8”
Brake: Alloy U-brake
Lever: Alloy, 2-finger design
Rear Hub: Verde 100, fully sealed, alloy, 14mm axle, 9-tooth driver
Front Hub: Verde 100, fully sealed, alloy, 3/8” axle
Sprocket: Verde Recon 25-tooth, chromoly
Cranks: Tubular chromoly 3-piece, 170mm
BB: 19mm sealed Mid
Chain: KMC 410, black
Pedals: Nylon composite platform
Front Rim: 6061 aluminum, single wall, 36-hole
Rear Rim: 6061 aluminum, single wall, 36-hole
Spokes: Black w/ silver nipples
Front Tire: 20 x 2.35” DUO Brand Stun 1, 65 psi
Rear Tire: 20 x 2.35” DUO Brand Stun 1, 65 psi
Seat: Verde Hex w/ integrated post
Seat Post: Uni-style, integrated, alloy, 25.4mm diameter, 175mm length
Seat Clamp: Alloy, black
Grips: Verde Leaf grips w/ press-in Verde bar ends
Weight: 24.5 lbs
