Frame |
ALUXX-grade aluminum, disc |
Fork |
SR Suntour XCE, QR, steel steerer 27.5" XS: 80mm, S: 100mm, M: 100mm 29" S: 100mm, M: 100mm, L: 100mm |
Shock |
N/A |
Handlebar |
Giant Connect Trail, 31.8mm 27.5" XS: 670mm, S: 670mm, M: 750mm 29" S: 670mm, M: 750mm, L: 750mm |
Grips |
Giant Sole-O |
Stem |
Giant Sport, 7-degree 27.5" XS: 40mm, S: 40mm, M: 50mm 29" S: 40mm, M: 50mm, L: 50 |
Seatpost |
Giant Sport, 30.9mm 27.5" XS: 300mm, S: 300mm, M: 375mm 29" S: 375mm, M: 375mm, L: 375mm |
Saddle |
Liv Sport |
Pedals |
platform |
Shifters |
Shimano SL-M315, 2x7 |
Front Der. |
Shimano FD-M315 |
Rear Der. |
Shimano Tourney |
Brakes |
TKB-172, mechanical, [F]160mm, [R]160mm |
Brake Levers |
RS360A, mechanical |
Cassette |
Shimano HG200-7, 12-32 |
Chain |
KMC Z7 |
Crankset |
ProWheel Forged, 22/36, chain guard 27.5" XS: 165mm, S: 165mm, M: 170mm 29" S: 170mm, M: 170mm, L: 175mm |
Bottom Bracket |
cartridge |
Rims |
27.5": Giant GX03V 27.5", alloy, double wall, 21mm inner width 29": Giant GX03V 29", alloy, double wall, 21mm inner width |
Hubs |
alloy, sealed bearing |
Spokes |
stainless |
Tires |
27.5": Kenda Booster 27.5x2.4, wire bead 29": Kenda Booster 29x2.4, wire bead |
Extras |
2.4" max tire size, 32t max chainring |
