Motor
Giant SyncDrive Pro2 85Nm, PedalPlus 6-Sensor technology
-
Controller
Giant RideControl Ergo3, grip integrated remote
-
Display
Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
-
Battery
Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible (exculde S size)
-
Charger
Giant EnergyPak 6A smart charger, 60% in 2:15h
-
Connectivity
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
-
Sizes
S, M, L, XL
-
Colours
Sangria / Black
-
Frame
ALUXX SL-grade aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, Universal Derailleur Hanger
-
Fork
Fox 38 Rhythm E-Optimized, 29er, 170mm travel, 44mm offset, Grip damper Sweep-Adj Boost, Kabolt-X 110
-
Shock
Fox Float X Performance, EVOL Large Volume sleeve, 205x62.5mm Trunnion mount, custom tuned, recommended sag: 30%
-
Handlebar
Giant Contact Trail, 35x800mm
-
Grips
Giant Tactal Pro-E, tapered design, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL)
-
Stem
Giant Contact SL 35
-
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/L:170/XL:200)
-
Saddle
Velo VL3594
-
Pedals
Flatpedal
-
Shifters
Shimano Cues LinkGlide
-
Front Derailleur
MRP 1X HD2 custom co-molded chain guide
-
Rear Derailleur
Shimano Cues LinkGlide 11-speed
-
Brakes
Shimano Deore, BR-M6120, 4-piston, hydraulic disc, 220mm[F], 203mm [R]
-
Brake Levers
Shimano Deore, I-spec EV
-
Cassette
Shimano Cues LinkGlide, CS-LG400-11, 11-50T, 11-speed
-
Chain
Shimano LinkGlide, CN-LG500
-
Crankset
Praxis N.W. 36T Cold Forged 4130 premium steel Praxis e-HD forged crankarm set (S/M:160mm, L/XL:165mm)
-
Bottom Bracket
n/a
-
Rims
Giant AM30, Tubeless ready, 30mm inner width, 29" [F] / 27.5" [R]
-
Hubs
Shimano MT410, Boost, Center-Lock, [F] 110x15 [R] 148x12mm HG Drive Body Thru-axle
-
Spokes
Sapim E-Lite [R] Race [F], e-bike optimized
-
Tires
Maxxis Minion DHF 29x2.6"" foldable, Tubeless, EXO+, 3C MaxxTerra[F] Maxxis High Roller II 27.5x2.5"" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
-
Extras
Tubeless kit (liquid, valves, levers, manual, tool)
-
Lock
Torx 25 Battery Lock with built-in Torque limiter
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
